Cast steel gate valves PN 16 MPa

Main page /Catalog/ Products / МЗТА /Steel gate valves

Cast steel gate valves are produced for installation on pipelines as lock units. Ends: flange ends, welded ends; Operation: handwheel, gear box, actuator; Service life: 10 years; Warranty: 24 months.

31s45ss 31s545ss 31s945ss 31cs45ss 31cs545ss 31cs945ss

Characteristics of functionality

  • Medium: Hot and cold water, steam, oil, petrol, gas;
  • Medium temperature: from −40°С to +45°С;
  • Environment temperature: from -40°C to +425°C;

Materials

  • 1. Body – carbon steel;
  • 2. Bonnet – carbon steel;
  • 3. Wedge (Disks) – carbon steel with stainless steel welding working surface;
  • 4. Stem – stainless steel;
  • 5. Stem nut – carbon steel / brass;
  • 6. Nut - carbon steel;
  • 7. Stud, bolt  - carbon steel;
  • 8. Eye bolt – carbon steel;
  • 9. Gasket – asbestos / graphite;
  • 10. Gland packing – asbestos / graphit




Dimensions

DN L D H2
50 300 195 290
80 390 230 400
100 450 265 535
150 559 350 725
200 660 430 1055
250 787 500 1255
