Cast steel gate valves PN 4,0 MPa

Main page /Catalog/ Products / МЗТА /Steel gate valves

Cast steel gate valves are produced for installation on pipelines as lock units. Ends: flange ends, welded ends; Operation: handwheel, gear box, actuator; Service life: 10 years; Warranty: 24 months.

TYPE DESIGNATION

30s15ss 30s515ss 30с915нж 30лс15нж 30лс515нж 30лс915нж 30cs15ssT 30нж15нж 30нж915нж

Characteristics of functionality

  • Medium: Hot and cold water, steam, oil, petrol, gas;
  • Medium temperature: from −40°С to +45°С;
  • Environment temperature: from -40°C to +425°C;

Materials

  • 1. Body – carbon steel / stainless steel;
  • 2. Bonnet – carbon steel / stainless steel;
  • 3. Wedge (Disks) – carbon steel with stainless steel welding working surface / stainless steel;
  • 4. Stem – stainless steel;
  • 5. Stem nut – carbon steel / brass;
  • 6. Nut - carbon steel;
  • 7. Stud, bolt  - carbon steel;
  • 8. Eye bolt – carbon steel;
  • 9. Gasket – asbestos / graphite;
  • 10. Gland packing – asbestos / graphite;
  • 12. Redusing gear – cone or cylinder reducing gear;
  • 13. Working surface of the body – stainless steel welding;
  • 14. Working surface of the wedge (discs) – stainless steel welding.





Dimensions

DN L D H3
300 500 510 1720
400 600 655 2040
Production

Cast steel gate valves 30cs15ss

Cast steel gate valves 30s15ss
